Features

• A3 Duplex Scanner
• 80 PPM /160 IPM @300dpi A4 grayscale, landscape
• 100 Sheet ADF Capacity
• Support long paper size scan up to 50"
• Wake-Up function
• Scan to searchable PDF
• Easy Configure of Each Single-Touch Function Buttons with AP Software
• TWAIN and WIA Drivers - Allows Full Document Management Solutions Implementations

CCD Sensor x 2

600 dpi

600 x 600 dpi

1. 100 sheets (A4/Letter, 70 g/m² or 18 Lbs), Max. thickness under 10mm (0.4")

2. 50 sheets (A3, 70 g/m2 or 18 Lbs)

3. 20 sheets (Business Cards)

4. Plastic Card (Portrait Loading), Max. thickness under 1.2 mm.

Note: Maximum ADF capacity varies, depending upon paper weight.

80 ppm/ 160 ipm (Grayscale/B&W mode, 300 dpi, A4 Landscape)

45 ppm/ 90 ipm (Color mode, 200 dpi, A4 Landscape) 30 ppm/ 60 ipm (Color mode, 300 dpi, A4 Landscape) Note: Results may vary depending upon your scanning application, computer processor and system memory.

Max. 297 x 1270 mm (11.69" x 50") Min. 13.2 x 13.2 mm (0.52" x 0.52")

Max. 305 x 1300 mm (12" x 51") Min. 50.8 x 63.5 mm (2" x 2.5")

40 to 220 g/m² (10 to 58 Lbs)

5,000

4 Buttons: Up, Down, Scan, Standby 9 Function Keys: Scan, PDF, OCR, File, E-Mail, Copy, BCR, FTP, DI Capture. All Customizable.

24 Vdc/ 2.7 A

USB 2.0/RJ45

9 Kgs (19.8 Lbs)

436 x 262 x 266 mm (17.16" x 10.31" x 10.47")

TWAIN Compliant

Windows 2000 / XP / Vista / 7

Plustek DocAction Plustek DI Capture ABBYY FineReader Sprint Plustek DI Express (SC/TC/JP/KR) Hotcard BizCard Finder
